IMPULSE NB200E

Network Encoder and Streamer

SKU: WELLAV-SENCORE-NB200E
Categorías: BROADCAST, Encoders, Plataformas Digitales

Impulse es un codificador / transmisor de un solo canal para procesamiento de audio y video.

Permite codificación profesional y transmisión IP para codificación y carga en vivo, inserción de canales, transmisión en vivo, reproducción / transmisión de programas locales / AD, reuniones remotas, señalización digital, etc. Además, Impulse tiene la capacidad de transmitir y grabar video en vivo al mismo tiempo.

Streaming

Protocols

Live: UDP, RTSP, RTMP, HLS
Server Mode:

  • Direct streaming to connected audience
  • RJ45, limited accessing numbers
Operating Modes

Live

Encoding and IP streaming

Recording

Local: USB Flash, SD Card
Format: TS, MOV/MP4
Circling recording (by time or size of File

Playback

Local: USB Flash, SD Card
Format: TS, MOV/MP4
In-order playlist
IP output

Management

Configuration

Web-GUI (easy or advanced mode) or front panel
Power-on and play (by pre-setup or last configuration)

Status/Monitoring

LCD display of status
Remote monitoring of status and current program

Physical & Environment

Dimensions

144 x118 x 38 mm (5.6″x4.6″x1.5″)

Weight

0.3Kg (0.66 lb)

Power

12V DC port x 1
Max. 9W

Operating Temperature

10~40℃

Channels

Video

1 channel of H.264 or H.265 SD/HD program encoding

Audio

1 pair of MPEG1L2, AAC or AC3 (optional) audio

Physical Interfaces

Input

1 x HDMI
1 x CVBS (3.5mm) for CC input
1 x SDI (option)
1 x Audio interface (3.5mm)
1 x Serial port (3.5mm)

Output

1 x RJ45
1 x HDMI

Other I/O

1 x USB 2.0, 1 x SD Card Standard Interface
LCD x 1, Front button x 5, Reset button x 1

Encoding

H.264

BP/MP/HP@L5.1

H.265

MP@L5.1

Resolution

Input:
1920×1080@60p/50p/30p/25p
1920×1080@60i/50i
1280x720p@60p/50p
720×576@50i
720×480@60i

Output:
1920×1080@60p/50p/30p/25p
1920×1080@60i/50i
1280x720p@60p/50p
720×576@50i
720×480@60i
704×576@30p/60i
640×480@30p/60i
640×360@30p/60i

Video Bitrate: 1 – 12Mbps
Closed Captions: Supported
Rate Control: CBR/VBR
GOP Control: Supported
Aspect Ratio: Automatic or Manual (4:3 or 16:9)
Audio Profile: MPEG-1 Layer II, AAC (HE/LC), AC3 (optional)
Audio Bitrates:

MPEG-1 Layer II: 64 – 384Kbps
AAC (HE/LC): 48 – 448Kbps
AC3 (optional): 128 – 448Kbps
Audio Mode: Stereo (2.0, including down-mix)
Audio Sampling Rate: 48kHz
Audio Volume Leveling: -12 – 12dB
