LMS-VIA

IP and SDI routing solution

EVS
SKU: EVS-LMS-VIA
Categorías: BROADCAST, EVS, Servidores y Sistemas para Producción en Vivo, Switchers y Sistemas en Vivo

    The new replay experience

    Designed in close collaboration with our community of EVS operators, LSM-VIA offers unprecedented usability, flexibility, speed and control for all your live operations. Working together with the XT-VIA and XT-GO servers and interacting seamlessly with all other VIA products, the new replay and highlights solution opens up exciting new workflows and provides faster and direct access to all the content on the network. And with full IP connectivity and software-defined technology onboard, LSM-VIA ensures you’re ready to address all future live production expectations.

    Core benefits

    OPERATOR USABILITY

    Better ergonomics, a new integrated touchscreen, and direct access to functions in a customizable layout allow you to create your replays and highlights with a level of intuitiveness that is second to none.

    GREATER FLEXIBILITY AND SCALABILITY

    By interacting seamlessly with other EVS solutions in the VIA microservices ecosystem, LSM-VIA opens up flexible new workflows that adapt perfectly to each production and scale as you need.

    SPEED UP YOUR OPERATIONS

    Get access to more functionalities, faster, thanks to the remote’s programmable buttons, shortcut functions, simple tactile control and semi-automated functionalities

    MORE CONTROL

    Manage and visualize multi-angle live content from any server on the network transparently and without delays, and a second viewer that acts as an interface to the whole VIA production environment.

    IP CONNECTIVITY

    With native IP connectivity onboard, you can assign channels more dynamically for maximum flexibility and benefit from direct access to content anywhere on the network.

    ONE CONTROL INTERFACE

    One control interface for XT-VIA and XT-GO with an easy transition from EVS’ well-known industry standard LSM remote.

    Components

    LSM-VIA Remote

    Live slow motion remote controller

    • Familiar layout
    • Streamlined ergonomics
    • Programmable buttons
    • Direct access to functions
    • Intuitive touchscreen panel
    • Semi-automated control
    • Integrated with XtraMotion for super slow-motion clip creation

    XClient

    Thin client for viewer applications

    • Mountable anywhere due to small size
    • IP connection to remote controller
    • Can reach any server on the network
    • Playlist management and others on first screen
    • MultiReview on a second screen

    Operator screen

    A screen showing your clips and trains
    • Intuitive content management
    • Keyboard and mouse navigation
    • Powerful search functionality
    • Fast browsing and selection
    • Enrich clip metadata
    • Playlist management and editing
    • Contextual layouts

    MultiReview screen

    A second screen to browse multiple camera angles simultaneously
    • Client-based video review application
    • Multi-angle view using low-res feeds from all servers in the network
    • Browse from a single operator position up to 16 multi-cam proxy feeds in one layout
    • Create and stack layouts to expand the available live feeds
    • Combines the overview of a director, with the possibilities of a replay operator

    XT Multiviewer screen

    Live multiviewer feed coming from an XT server
    • Browse high resolution signals feeding the server
    • Available on both SDI as well as ST2110
    • Runs on an XT-VIA or XT-GO server
    • Choose between various multiview layouts
    • External sources possible
    • Support for Tally, OSD and audio bars
    CARACTERISTICAS

    Key features

    • EVS reliability and reactivity
    • Multicamera ingest & playback
    • Slow-motion and super slow-motion control
    • Highlight editing tools
    • Full IP connectivity
    • Customizable shortcuts for even faster operations
    • Search across the EVS network
    • Familiar controller design with streamlined ergonomics
    • Export and flatten media to any destination
    • Compatible with XT-VIA and XT-GO servers
    • MultiReview: browse up to 16 multicam proxy feeds from a single position

    LSM-VIA works with both XT-VIA as well as with XT-GO. Using it in combination with XT-VIA allows you to fully benefit from all its power and potential. In combination with XT-GO you enable all the advanced replay features you have with an LSM-VIA compared to the LSM-GO.

    Get the most out of your EVS equipment

    At EVS, we understand how important it is for our customers to gain an edge in the live production environment.  That’s why we’re empowering operators and technical engineers to become advanced users of our technology – leading to better production values, streamlined workflows and better ROI from your EVS investment.

    General

    Channels
    8ch FHD and HD (720p, 1080i, 1080p)
    4ch UHD-4K (2160p)

    Choice of one codec
    UHD-4K:  XAVC-Intra, DNxHR
    HD/FHD:  XAVC-I, AVC-I, DNxHD or ProRes

    SDI I/O
    1.5G-SDI, 3G-SDI and 12G-SDI selectable in software settings

    IP/IO
    10G Ethernet SFP+
    IP ST2110 (-10, -20, -21, -30, -40)
    NMOS IS-04, IS-05, EMBER+
    PTP

    Audio
    192 uncompressed audio tracks
    Embedded, AES and MADI support

    Storage
    Internal storage of 11TB
    Expandable to 22TB
    Recording capacity of up to 140 hours at 100Mbps
    Hot swap storage

    Multi-Network Onboard
    EVS XNet-GO (3G-SDTI)
    Dual 10Gbps media sharing network
    Redundant 1Gbps management LAN ports

    Embedded Multiviewer
    2 external inputs
    4 individual outputs
    10 different layouts
    Tally support
